4 Way DiSEqC Switch
Connects up to 4 LNB's or Satellite Dishes
4 way DiSEqC switch enables the connection of four LNB's or 4 satellite dishes to one satellite receiver that has DiSEqC control.
DiSEqC stands for digital satellite equipment control. This switch will allow up to 4 satellite dishes or LNB's to be connected to 1 satellite receiver using only one coaxial cable. It is not necessary to populate all of the inputs if they are not required. Can be used as a 2 or 3 way switch if required. The DiSEqC switch is weatherproof and should be mounted vertically in a chosen location to prevent water running into the connections. The plastic housing of the switch can be pole or wall mounted.
specifications:
DiSEqC Version: 2.0
Type: 4-way (A/B)
Frequency range: 950 - 2300 MHz
Isolation input: >35 dB
Operating voltage: 12 - 20 V
Power consumption: 10 mA
Insertion loss: 3 dB
Switching signal: 22 kHz
Max. DC power passing: 500 mA to LNB port
Outdoor operating temperature: -30 ºC ~ +60 ºC
Durable housing
Splash-proof
Low insertion loss
DiSEqC version 2.0., backwards compatible with older receivers with DiSEqC versions 1.0,1.1 and 1.2 fitted.
